GYTY53




GYTA Armored Loose Tube Single Jacket/Single Armor fiber optic cables are designed to provide high fiber counts with the flexibility
and versatility required for today's most demanding installations, including duct and underground conduit.


Product Construction:
1. Fiber:2-288 fiber Multi-loose tube gel-filled
2. Central Strength Member: Fiberglass reinforced Platic (FRP) or steel wire.
3. Armor:Aluminum Tape Armor
4. Outer Jacket:Black UV Polyethylene(PE)


Features:
Up to 288 fibers.
Loose tube gel-filled construction for superior fiber protection.
Aluminum tape armor to protect cable from mechanical damage.

UV and waterproof design.


Structure and Technical Specifications

Fiber
Count
Nominal
Diameter (mm)
Nominal
Weight
(kg/km)
Max Fibers
per Tube
Max
No. of
(Tubes+
fillers)
Allowable Tensile
Load (N)
Allowable Crush
Resistance
(N/100mm)
Short Term Long Term Short Term Long Term
2~30 13.2 162 6 5 3000 1000 3000 1000
32~48 13.8 175 8 6 3000 1000 3000 1000
50~72 14.6 205 12 6 3000 1000 3000 1000
74~96 16 230 12 8 3000 1000 3000 1000
98~144 17.6 285 12 12 3000 1000 3000 1000
>144 Available upon customer's request

Note:

1. For flame retardant cable, outer sheath can be made of low-smoke halogen-free (LSZH) material.
2.Upon customer's request, cables with longitudinal color strip on outer sheath can be offered.
More details, please refer to GYTY53 series.
3. Special cable structure can be designed and manufactured on customer's request.
