The fibers are positioned in loose tubes that are made of high-modulus plastic and filled with tube gel. The tubes (and fillers) are stranded around a metallic central strength member to form a cable core.The core is filled with water-blocking compound and armored with corrugated steel tape(CST). Stranded steel wires are applied as the messenger. Finally, a figure-8 PE outer jacket is extruded.
Product Construction:
Fiber:
2-24 fibers
Uni-loose tube gel-filled
Messenger member:
2.1mm galvanized steel
Outer Jacket:
Black UV and waterproof polyethylene (PE).
Features: Uni-Loose tube gel-filled construction for superior fiber protection.
Self-supporting Figure 8 design.
| No | 1 | 2 | 3 | 4 | 5 | 6 |
| Color | Blue | Orang e | Green | Brown | Slate | White |
| No | 7 | 8 | 9 | 10 | 11 | 12 |
| Color | Red | Black | Yellow | Violet | Pink | Aqua |
| No | 13 | 14 | 15 | 16 | 17 | 18 |
| Color | Blue+R | Orang e +R | Green+R | Brown+R | Slate+R | White+R |
| No | 19 | 20 | 21 | 22 | 23 | 24 |
| Color | Red+R | Natural+R | Yellow+R | Violet+R | Pink+R | Aqua +R |
