component:
| Fiber Counts | 24F |
| OD of Loose Tube(mm) | 2.5±0. 1 mm |
| Max Fiber Counts/tube | 8 |
| Center Strength member(mm) | 2.6 ± 0.1 mm |
| Messenger steel wire | 7*1.6 mm |
| Messenger wire sheath thickness | 1.1 ± 0.1 mm |
| Connection | 2.0*2.0 ± 0.1 mm |
| Outer Sheath Thickness | 1.7 ± 0.1 mm |
| Outer Sheath Material | Black MDPE |
| OD of Cable | 12.5 ± 0.5 / 21.5 ±5% |
| Net weight ( kg/km) | 280±15% |
| Tensile performance(N) | 30000 |
| Operating temperature | - 20ºC~+60ºC |
| Store/Transport temperature | - 20ºC~+60ºC |
| Installation temperature |
- 10ºC~+60ºC |
